Mini-OB - Pair of open-baffle loudspeakers 50W / 97dB

Mini-OB - Pair of open-baffle loudspeakers 50W / 97dB

€9.999,00 EUR
€9.999,00 EUR
Sale Sold out
Taxes included. Shipping calculated at checkout.

The Mini-OB is the spiritual heritage of the Zélia.

Building on our work on the 215 Heritage loudspeaker range, we started from the central Alnico magnet motor base for the new 215 AL loudspeakers fitted to this loudspeaker.

We use this extended bass-midrange of 21cm in an open baffle, in order to preserve its legendary definition in the midrange.

Beyond 3 kHz it is supported by our TG1/4 renowned for its dynamics and transparency.

To extend the bass response, we use a second 215 AL filtered in 2.5 ways. This pair of 215s combined produce an emissive surface of 31cm, their 3mm travel offers a dynamic and articulated bass.

We opted for a quasi-optimal filtering of the second order Linkwitz-Riley type.



TECHNICAL CHARACTERISTICS
Yield : 97dB
Bandwidth : 50Hz-23KHz
Impedance: 4 Ω
power max. RMS : 50W
Number of ways: 2,5
Type of load: Baffle plan
Drivers : 2x 215 AL, 1x TG1/4
Connectors: Mono-wiring compatible with bananas or forks




FURTHER INFORMATION
Dimensions (WxHxD) Product: 300/600 x 1060 x 530 mm
Product Weight: 30 kg piece
Dimensions (LxHxP) Carton : 590 x 1235 x 740 mm
Box weight: 35 kg piece
Number of boxes: 2
View full details

High-Precision Craftsmanship: Made in France

Each Supravox loudspeaker inherits expertise born in the 1950s. From the iconic 215 RTF 64 to today's innovations, our loudspeakers are entirely hand-assembled in our workshop just outside Paris. A French standard of perfection that defies time to deliver pure musical emotion.

  • The Artisan's Touch

    At the heart of our factory on the outskirts of Paris, each voice coil is hand-wound with micrometric tension. We use ultra-light supports and high-purity conductors to minimize moving mass. It is this extreme lightness that gives our loudspeakers their legendary responsiveness and their ability to reveal the finest details.

  • The Hand and the Spirit

    Each loudspeaker is a unique piece, assembled by craftsmen whose expertise has been passed down for decades. The precision of the centering and the tension of the suspensions are adjusted by touch, a sensitivity that no machine can replicate. This artisanal assembly guarantees perfect fluidity of movement and exceptional longevity.

  • Exponential Paper Cones

    Our cones are made from a proprietary recipe of long-fiber paper, manually processed to achieve an ideal balance of rigidity and damping. The exponential profile, pioneered by Supravox, ensures homogeneous sound diffusion. The result is an organic timbre and strikingly realistic vocal presence.

  • Magnetic Alchemy

    Beyond the simple magnet, we master energy. In our factory on the outskirts of Paris, we forge Alnico 5 motors and Field Coil systems capable of saturating the air gap with absolute precision. This controlled power offers lightning-fast dynamics and almost zero distortion, hallmarks of Supravox's high sensitivity.

  • Signal Purity

    Perfection often comes from subtraction. By designing full-range loudspeakers capable of covering most of the spectrum, we eliminate the need for crossover filters. The signal travels directly from your amplifier to the cone, preserving perfect phase coherence and a holographic soundstage of complete transparency.

  • Tested for Eternity

    Each unit leaving our workshops undergoes a rigorous testing protocol: frequency analysis, impedance measurement, and tactile inspection of the excursion. But the final verdict belongs to the human ear. Each loudspeaker is validated by our technicians, ensuring that your investment will remain an exceptional instrument for decades to come.
